FDB20AN06A0 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D²PAK
- Description: MOSFET N-CH 60V 9A/45A TO263AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDB20AN06A0 Specifications:
- MfrPart.: FDB20AN06A0
- Mfr: onsemi
- Description: MOSFET N-CH 60V 9A/45A TO263AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: PowerTrench®
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 9A (Ta), 45A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 20mOhm @ 45A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 19 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 950 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 90W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D²PAK
- FDB20AN06A0 onsemi (ON), MOSFET N-CH 60V 9A/45A TO263AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDB20AN06A0, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
