SBAT54CTT1G onsemi DIODE ARRAY SCHOTTKY 30V SC75
SBAT54CTT1G Images
SBAT54CTT1G Images
SBAT54CTT1G
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: SC-75, SOT-416
  • Description: DIODE ARRAY SCHOTTKY 30V SC75
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SBAT54CTT1G Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SBAT54CTT1G Specifications:
  • Mfr Part: SBAT54CTT1G
  • Mfr: onsemi
  • Description: DIODE ARRAY SCHOTTKY 30V SC75
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
  • Item12: Tape & Reel (TR)
  • Series: -
  • Part Status: Active
  • Diode Configuration: 1 Pair Common Cathode
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 30 V
  • Current - Average Rectified (Io) (per Diode): 200mA (DC)
  • Voltage - Forward (Vf) (Max) @ If: 800 mV @ 100 mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 2 µA @ 25 V
  • Operating Temperature - Junction: -55°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: SC-75, SOT-416
  • SBAT54CTT1G onsemi (ON), DIODE ARRAY SCHOTTKY 30V SC75, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
