FDB0690N1507L Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-263-7
- Description: MOSFET N-CH 150V 3.8A TO263-7
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDB0690N1507L Specifications:
- MfrPart.: FDB0690N1507L
- Mfr: onsemi
- Description: MOSFET N-CH 150V 3.8A TO263-7
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 150 V
- Current-ContinuousDrain(Id)@25°C: 3.8A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 6.9mOhm @ 17A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 115 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 8.775 pF @ 75 V
- FETFeature: -
- PowerDissipation(Max): 250W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-263-7
- FDB0690N1507L onsemi (ON), MOSFET N-CH 150V 3.8A TO263-7, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
FDB0690N1507L, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
