MC74VHC1G135DF2G Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: SC-88A (SC-70-5/SOT-353)
- Description: IC GATE NAND 1CH 2IN SC88A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MC74VHC1G135DF2G Specifications:
- MfrPart.: MC74VHC1G135DF2G
- Mfr: onsemi
- Description: IC GATE NAND 1CH 2IN SC88A
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR)
- Series: 74VHC
- PartStatus: Obsolete
- LogicType: NAND Gate
- NumberofCircuits: 1
- NumberofInputs: 2
- Features: Schmitt Trigger, Open Drain
- Voltage-Supply: 2V ~ 5.5V
- Current-Quiescent(Max): 1 µA
- Current-OutputHighLow: -, 8mA
- LogicLevel-Low: 0.65V ~ 1.45V
- LogicLevel-High: 2.25V ~ 3.7V
- MaxPropagationDelay@VMaxCL: 9.7ns @ 5V, 50pF
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Surface Mount
- SupplierDevicePackage: SC-88A (SC-70-5/SOT-353)
- MC74VHC1G135DF2G onsemi (ON), IC GATE NAND 1CH 2IN SC88A, Integrated Circuits (ICs)~Logic - Gates and Inverters
MC74VHC1G135DF2G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
