FAN7093-F085 Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: TO-263-8, D²Pak (7 Leads + Tab), TO-263CA
- Description: IC DRVR HALF BRIDGE PN 8-TO263
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FAN7093-F085 Specifications:
- MfrPart.: FAN7093-F085
- Mfr: onsemi
- Description: IC DRVR HALF BRIDGE PN 8-TO263
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q100
- PartStatus: Obsolete
- OutputConfiguration: Half Bridge
- Applications: DC Motors, General Purpose
- Interface: Logic
- LoadType: Inductive
- Technology: DMOS
- RdsOn(Typ): 18.2mOhm LS (Max), 12.3mOhm HS (Max)
- Current-Output/Channel: 46A
- Current-PeakOutput: 88A
- Voltage-Supply: 7V ~ 18V
- Voltage-Load: 7V ~ 18V
- OperatingTemperature: -40°C ~ 150°C (TJ)
- Features: Latch Function, Slew Rate Controlled, Status Flag
- FaultProtection: Current Limiting, Over Temperature, Over Voltage, Short Circuit, UVLO
- MountingType: Surface Mount
- Package/Case: TO-263-8, D²Pak (7 Leads + Tab), TO-263CA
- FAN7093-F085 onsemi (ON), IC DRVR HALF BRIDGE PN 8-TO263, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
FAN7093-F085, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
