FDD6685 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252AA
- Description: MOSFET P-CH 30V 11A/40A TO252
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
FDD6685 Specifications:
- MfrPart.: FDD6685
- Mfr: onsemi
- Description: MOSFET P-CH 30V 11A/40A TO252
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerTrench®
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 11A (Ta), 40A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 20mOhm @ 11A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 24 nC @ 5 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 1715 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 52W (Ta)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252AA
- FDD6685 onsemi (ON), MOSFET P-CH 30V 11A/40A TO252, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
