FAN5609MPX onsemi LED DRIVER, 4-SEGMENT
FAN5609MPX Images
FAN5609MPX Images
  • Manufacturer: onsemi (ON)
  • Category: Integrated Circuits (ICs)~PMIC - LED Drivers Package/Case: 16-VQFN Exposed Pad
  • Description: LED DRIVER, 4-SEGMENT
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
FAN5609MPX Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
FAN5609MPX Specifications:
  • MfrPart.: FAN5609MPX
  • Mfr: Fairchild Semiconductor (Now part of ONsemi)
  • Description: LED DRIVER, 4-SEGMENT
  • Product Category: Integrated Circuits (ICs)~PMIC - LED Drivers
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • Type: DC DC Regulator
  • Topology: Switched Capacitor (Charge Pump)
  • InternalSwitch(s): Yes
  • NumberofOutputs: 4
  • Voltage-Supply(Min): 2.7V
  • Voltage-Supply(Max): 5.5V
  • Voltage-Output: -
  • Current-Output/Channel: 20mA
  • Frequency: 1MHz
  • Dimming: PWM
  • Applications: Backlight
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-VQFN Exposed Pad
  • FAN5609MPX onsemi (ON), LED DRIVER, 4-SEGMENT, Integrated Circuits (ICs)~PMIC - LED Drivers
FAN5609MPX, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
