HMA2701AV Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 4-SMD, Gull Wing
- Description: OPTOISO 3.75KV TRANSISTOR 4SMD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HMA2701AV Specifications:
- MfrPart.: HMA2701AV
- Mfr: onsemi
- Description: OPTOISO 3.75KV TRANSISTOR 4SMD
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Voltage-Isolation: 3750Vrms
- CurrentTransferRatio(Min): 150% @ 5mA
- CurrentTransferRatio(Max): 300% @ 5mA
- TurnOn/TurnOffTime(Typ): -
- Rise/FallTime(Typ): 3µs, 3µs
- InputType: DC
- OutputType: Transistor
- Voltage-Output(Max): 40V
- Current-Output/Channel: 80mA
- Voltage-Forward(Vf)(Typ): 1.3V (Max)
- Current-DCForward(If)(Max): 50 mA
- VceSaturation(Max): 300mV
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 4-SMD, Gull Wing
- HMA2701AV onsemi (ON), OPTOISO 3.75KV TRANSISTOR 4SMD, Isolators~Optoisolators - Transistor, Photovoltaic Output
HMA2701AV, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
