74OL6011S Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Logic Output Package/Case: 6-SMD, Gull Wing
- Description: OPTOISO 5.3KV OPEN COLL 6SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
74OL6011S Specifications:
- MfrPart.: 74OL6011S
- Mfr: onsemi
- Description: OPTOISO 5.3KV OPEN COLL 6SOIC
- Product Category: Isolators~Optoisolators - Logic Output
- Package: Tube
- Series: OPTOLOGIC™
- PartStatus: Obsolete
- NumberofChannels: 1
- Inputs-Side1/Side2: 1/0
- Voltage-Isolation: 5300Vrms
- CommonModeTransientImmunity(Min): 5kV/µs
- InputType: Logic
- OutputType: Open Collector, Schottky Clamped
- Current-Output/Channel: 40 mA
- DataRate: 15MBd
- PropagationDelaytpLH/tpHL(Max): 180ns, 120ns
- Rise/FallTime(Typ): 50ns, 5ns
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-Supply: 4.5V ~ 15V
- OperatingTemperature: 0°C ~ 70°C
- MountingType: Surface Mount
- Package/Case: 6-SMD, Gull Wing
- 74OL6011S onsemi (ON), OPTOISO 5.3KV OPEN COLL 6SOIC, Isolators~Optoisolators - Logic Output
74OL6011S, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
