IRL8113PBF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: HEXFET POWER MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
IRL8113PBF Specifications:
- MfrPart.: IRL8113PBF
- Mfr: onsemi
- Description: HEXFET POWER MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Bulk
- Series: HEXFET®
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 105A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 6mOhm @ 21A, 10V
- Vgs(th)(Max)@Id: 2.25V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 35 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2.84 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 110W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- IRL8113PBF onsemi (ON), HEXFET POWER MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
