2SB1124S-TD-E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-243AA
- Description: TRANS PNP 50V 3A PCP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2SB1124S-TD-E Specifications:
- MfrPart.: 2SB1124S-TD-E
- Mfr: onsemi
- Description: TRANS PNP 50V 3A PCP
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 3 A
- Voltage-CollectorEmitterBreakdown(Max): 50 V
- VceSaturation(Max)@IbIc: 700mV @ 100mA, 2A
- Current-CollectorCutoff(Max): 1µA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 140 @ 100mA, 2V
- Power-Max: 500 mW
- Frequency-Transition: 150MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-243AA
- 2SB1124S-TD-E onsemi (ON), TRANS PNP 50V 3A PCP, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
