NVTFWS014P04M8LTAG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-WDFN (3.3x3.3)
- Description: MOSFET P-CH 40V 11.3A/49A 8WDFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NVTFWS014P04M8LTAG Specifications:
- MfrPart.: NVTFWS014P04M8LTAG
- Mfr: onsemi
- Description: MOSFET P-CH 40V 11.3A/49A 8WDFN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 11.3A (Ta), 49A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 13.8mOhm @ 15A, 10V
- Vgs(th)(Max)@Id: 2.4V @ 420µA
- GateCharge(Qg)(Max)@Vgs: 26.5 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1734 pF @ 20 V
- FETFeature: -
- PowerDissipation(Max): 3.2W (Ta), 61W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-WDFN (3.3x3.3)
- NVTFWS014P04M8LTAG onsemi (ON), MOSFET P-CH 40V 11.3A/49A 8WDFN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
NVTFWS014P04M8LTAG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
