2N5772_D75Z Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Description: TRANS NPN 15V 0.3A TO92
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N5772_D75Z Specifications:
- MfrPart.: 2N5772_D75Z
- Mfr: onsemi
- Description: TRANS NPN 15V 0.3A TO92
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Box (TB)
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 300 mA
- Voltage-CollectorEmitterBreakdown(Max): 15 V
- VceSaturation(Max)@IbIc: 500mV @ 3mA, 300mA
- Current-CollectorCutoff(Max): 500nA
- DCCurrentGain(hFE)(Min)@IcVce: 30 @ 30mA, 400mV
- Power-Max: 350 mW
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- 2N5772_D75Z onsemi (ON), TRANS NPN 15V 0.3A TO92, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2N5772_D75Z, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
