HGT1S14N36G3VLT Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-262-3 Long Leads, I²Pak, TO-262AA
- Description: N-CHANNEL IGBT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HGT1S14N36G3VLT Specifications:
- MfrPart.: HGT1S14N36G3VLT
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: N-CHANNEL IGBT
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 390 V
- Current-Collector(Ic)(Max): 18 A
- Current-CollectorPulsed(Icm): -
- Vce(on)(Max)@VgeIc: 2.2V @ 5V, 14A
- Power-Max: 100 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: 24 nC
- Td(on/off)@25°C: -/7µs
- TestCondition: 300V, 7A, 25Ohm, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-262-3 Long Leads, I²Pak, TO-262AA
- HGT1S14N36G3VLT onsemi (ON), N-CHANNEL IGBT, Discrete Semiconductor Products~Transistors - IGBTs - Single
