2N5060G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Thyristors - SCRs Package/Case: TO-226-3, TO-92-3 Long Body
- Description: SCR 30V 800MA TO92-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N5060G Specifications:
- MfrPart.: 2N5060G
- Mfr: onsemi
- Description: SCR 30V 800MA TO92-3
- Product Category: Discrete Semiconductor Products~Thyristors - SCRs
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- Voltage-OffState: 30 V
- Voltage-GateTrigger(Vgt)(Max): 800 mV
- Current-GateTrigger(Igt)(Max): 200 µA
- Voltage-OnState(Vtm)(Max): 1.7 V
- Current-OnState(It(AV))(Max): 510 mA
- Current-OnState(It(RMS))(Max): 800 mA
- Current-Hold(Ih)(Max): 5 mA
- Current-OffState(Max): 10 µA
- Current-NonRepSurge5060Hz(Itsm): 10A @ 60Hz
- SCRType: Sensitive Gate
- OperatingTemperature: -40°C ~ 110°C
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 Long Body
- 2N5060G onsemi (ON), SCR 30V 800MA TO92-3, Discrete Semiconductor Products~Thyristors - SCRs
