NSV40301MDR2G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: SMALL SIGNAL BIPOLAR TRANSISTOR
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
NSV40301MDR2G Specifications:
- MfrPart.: NSV40301MDR2G
- Mfr: onsemi
- Description: SMALL SIGNAL BIPOLAR TRANSISTOR
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
- Package: Bulk
- Series: -
- PartStatus: Active
- TransistorType: 2 NPN (Dual)
- Current-Collector(Ic)(Max): 3A
- Voltage-CollectorEmitterBreakdown(Max): 40V
- VceSaturation(Max)@IbIc: 115mV @ 200mA, 2A
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 180 @ 2A, 2V
- Power-Max: 653mW
- Frequency-Transition: 100MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- NSV40301MDR2G onsemi (ON), SMALL SIGNAL BIPOLAR TRANSISTOR, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
NSV40301MDR2G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
