ZTX749 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 (TO-226AA)
- Description: TRANS PNP 25V 2A TO226
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ZTX749 Specifications:
- MfrPart.: ZTX749
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: TRANS PNP 25V 2A TO226
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP
- Current-Collector(Ic)(Max): 2 A
- Voltage-CollectorEmitterBreakdown(Max): 25 V
- VceSaturation(Max)@IbIc: 500mV @ 200mA, 2A
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 1A, 2V
- Power-Max: 1 W
- Frequency-Transition: 100MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 (TO-226AA)
- ZTX749 onsemi (ON), TRANS PNP 25V 2A TO226, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
ZTX749, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
onsemi (ON) Authorized Distributor | NHE is dedicated to providing first-quality, genuine onsemi components.
