WPH4003-1E Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-3PF
- Description: MOSFET N-CH 1700V 2.5A TO3PF
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
WPH4003-1E Specifications:
- MfrPart.: WPH4003-1E
- Mfr: onsemi
- Description: MOSFET N-CH 1700V 2.5A TO3PF
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1700 V
- Current-ContinuousDrain(Id)@25°C: 2.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 10.5Ohm @ 1.5A, 10V
- Vgs(th)(Max)@Id: -
- GateCharge(Qg)(Max)@Vgs: 48 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 850 pF @ 30 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 55W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-3PF
- WPH4003-1E onsemi (ON), MOSFET N-CH 1700V 2.5A TO3PF, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
WPH4003-1E, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
