UC2842BDG Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 14-SOIC (0.154, 3.90mm Width)
- Description: IC REG CTRLR PWM CM 14-SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UC2842BDG Specifications:
- MfrPart.: UC2842BDG
- Mfr: onsemi
- Description: IC REG CTRLR PWM CM 14-SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
- Package: Tube
- Series: -
- PartStatus: Active
- OutputType: Transistor Driver
- Function: Step-Up, Step-Up/Step-Down
- OutputConfiguration: Positive, Isolation Capable
- Topology: Boost, Flyback
- NumberofOutputs: 1
- OutputPhases: 1
- Voltage-Supply(Vcc/Vdd): 10V ~ 30V
- Frequency-Switching: Up to 500kHz
- DutyCycle(Max): 96%
- SynchronousRectifier: No
- ClockSync: No
- SerialInterfaces: -
- ControlFeatures: Frequency Control
- OperatingTemperature: -25°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 14-SOIC (0.154, 3.90mm Width)
- UC2842BDG onsemi (ON), IC REG CTRLR PWM CM 14-SOIC, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
UC2842BDG, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
