TND506MD-TL-E Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 16-SOIC (0.173, 4.40mm Width)
- Description: TRANSISTOR DRIVER FOR APPLICATIO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TND506MD-TL-E Specifications:
- MfrPart.: TND506MD-TL-E
- Mfr: Sanyo (Now Part of ONsemi)
- Description: TRANSISTOR DRIVER FOR APPLICATIO
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Bulk
- Series: -
- PartStatus: Active
- OutputConfiguration: Half Bridge (2)
- Applications: AC Motors, Bulbs, DC Motors, General Purpose
- Interface: Logic
- LoadType: Inductive, Capacitive, Resistive
- Technology: Power MOSFET
- RdsOn(Typ): -
- Current-Output/Channel: -
- Current-PeakOutput: 250mA, 500mA
- Voltage-Supply: 5V ~ 20V
- Voltage-Load: 600V (Max)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- Features: -
- FaultProtection: -
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.173, 4.40mm Width)
- TND506MD-TL-E onsemi (ON), TRANSISTOR DRIVER FOR APPLICATIO, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
TND506MD-TL-E, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
