TN6714A Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-226-3, TO-92-3 (TO-226AA)
- Description: TRANS NPN 30V 2A TO226-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TN6714A Specifications:
- MfrPart.: TN6714A
- Mfr: Fairchild Semiconductor (Now part of ONsemi)
- Description: TRANS NPN 30V 2A TO226-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 2 A
- Voltage-CollectorEmitterBreakdown(Max): 30 V
- VceSaturation(Max)@IbIc: 500mV @ 100mA, 1A
- Current-CollectorCutoff(Max): 100nA (ICBO)
- DCCurrentGain(hFE)(Min)@IcVce: 50 @ 1A, 1V
- Power-Max: 1 W
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-226-3, TO-92-3 (TO-226AA)
- TN6714A onsemi (ON), TRANS NPN 30V 2A TO226-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
