TL494CDR2G Images
- Manufacturer: onsemi (ON)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: IC REG CTRLR BCK/PSH-PULL 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TL494CDR2G Specifications:
- MfrPart.: TL494CDR2G
- Mfr: onsemi
- Description: IC REG CTRLR BCK/PSH-PULL 16SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: SWITCHMODE™
- PartStatus: Active
- OutputType: Transistor Driver
- Function: Step-Down, Step-Up/Step-Down
- OutputConfiguration: Positive
- Topology: Buck, Push-Pull
- NumberofOutputs: 2
- OutputPhases: 1
- Voltage-Supply(Vcc/Vdd): 7V ~ 40V
- Frequency-Switching: 200kHz
- DutyCycle(Max): 48%
- SynchronousRectifier: Yes
- ClockSync: No
- SerialInterfaces: -
- ControlFeatures: Dead Time Control, Frequency Control
- OperatingTemperature: 0°C ~ 70°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- TL494CDR2G onsemi (ON), IC REG CTRLR BCK/PSH-PULL 16SOIC, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
TL494CDR2G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
