TIP41AG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-220-3
- Description: TRANS NPN 60V 6A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TIP41AG Specifications:
- MfrPart.: TIP41AG
- Mfr: onsemi
- Description: TRANS NPN 60V 6A TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 6 A
- Voltage-CollectorEmitterBreakdown(Max): 60 V
- VceSaturation(Max)@IbIc: 1.5V @ 600mA, 6A
- Current-CollectorCutoff(Max): 700µA
- DCCurrentGain(hFE)(Min)@IcVce: 15 @ 3A, 4V
- Power-Max: 2 W
- Frequency-Transition: 3MHz
- OperatingTemperature: -65°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- TIP41AG onsemi (ON), TRANS NPN 60V 6A TO220AB, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
