TIP33CG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-247-3
- Description: TRANS NPN 100V 10A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TIP33CG Specifications:
- MfrPart.: TIP33CG
- Mfr: onsemi
- Description: TRANS NPN 100V 10A TO247
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 10 A
- Voltage-CollectorEmitterBreakdown(Max): 100 V
- VceSaturation(Max)@IbIc: 4V @ 2.5A, 10A
- Current-CollectorCutoff(Max): 700µA
- DCCurrentGain(hFE)(Min)@IcVce: 20 @ 3A, 4V
- Power-Max: 80 W
- Frequency-Transition: 3MHz
- OperatingTemperature: -65°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- TIP33CG onsemi (ON), TRANS NPN 100V 10A TO247, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
