TIP141 Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-218-3
- Description: TRANS DARLINGTON NPN 80V 10A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TIP141 Specifications:
- MfrPart.: TIP141
- Mfr: onsemi
- Description: TRANS DARLINGTON NPN 80V 10A
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 10 A
- Voltage-CollectorEmitterBreakdown(Max): 80 V
- VceSaturation(Max)@IbIc: -
- Current-CollectorCutoff(Max): -
- DCCurrentGain(hFE)(Min)@IcVce: 1000 @ 5A, 4V
- Power-Max: 125 W
- Frequency-Transition: -
- OperatingTemperature: -65°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-218-3
- TIP141 onsemi (ON), TRANS DARLINGTON NPN 80V 10A, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
