TIL117M Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-DIP (0.300, 7.62mm)
- Description: OPTOISO 7.5KV TRANS W/BASE 6DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TIL117M Specifications:
- MfrPart.: TIL117M
- Mfr: onsemi
- Description: OPTOISO 7.5KV TRANS W/BASE 6DIP
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 7500Vpk
- CurrentTransferRatio(Min): 50% @ 10mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 10µs, 10µs (Max)
- Rise/FallTime(Typ): 2µs, 2µs
- InputType: DC
- OutputType: Transistor with Base
- Voltage-Output(Max): 30V
- Current-Output/Channel: -
- Voltage-Forward(Vf)(Typ): 1.2V
- Current-DCForward(If)(Max): 60 mA
- VceSaturation(Max): 400mV
- OperatingTemperature: -40°C ~ 100°C
- MountingType: Through Hole
- Package/Case: 6-DIP (0.300, 7.62mm)
- TIL117M onsemi (ON), OPTOISO 7.5KV TRANS W/BASE 6DIP, Isolators~Optoisolators - Transistor, Photovoltaic Output
TIL117M, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
