TIL1133S Images
- Manufacturer: onsemi (ON)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 6-SMD, Gull Wing
- Description: OPTOISO 5.3KV DARL W/BASE 6SMD
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TIL1133S Specifications:
- MfrPart.: TIL1133S
- Mfr: onsemi
- Description: OPTOISO 5.3KV DARL W/BASE 6SMD
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Obsolete
- NumberofChannels: 1
- Voltage-Isolation: 5300Vrms
- CurrentTransferRatio(Min): 300% @ 10mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 350ns, 55µs
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Darlington with Base
- Voltage-Output(Max): 30V
- Current-Output/Channel: -
- Voltage-Forward(Vf)(Typ): 1.2V
- Current-DCForward(If)(Max): 100 mA
- VceSaturation(Max): 1.25V
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Surface Mount
- Package/Case: 6-SMD, Gull Wing
- TIL1133S onsemi (ON), OPTOISO 5.3KV DARL W/BASE 6SMD, Isolators~Optoisolators - Transistor, Photovoltaic Output
