TIG111BF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 23A 2W TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TIG111BF Specifications:
- MfrPart.: TIG111BF
- Mfr: onsemi
- Description: IGBT 600V 23A 2W TO220
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: NPT
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 23 A
- Current-CollectorPulsed(Icm): 92 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 10A
- Power-Max: 2 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 63 nC
- Td(on/off)@25°C: 43ns/175ns
- TestCondition: 300V, 10A, 30Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- TIG111BF onsemi (ON), IGBT 600V 23A 2W TO220, Discrete Semiconductor Products~Transistors - IGBTs - Single
TIG111BF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
