TIG056BF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 400V 30W TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TIG056BF Specifications:
- MfrPart.: TIG056BF
- Mfr: onsemi
- Description: IGBT 400V 30W TO220
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 430 V
- Current-Collector(Ic)(Max): -
- Current-CollectorPulsed(Icm): 240 A
- Vce(on)(Max)@VgeIc: 5V @ 15V, 240A
- Power-Max: 30 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: -
- Td(on/off)@25°C: 46ns/140ns
- TestCondition: 320V, 240A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- TIG056BF onsemi (ON), IGBT 400V 30W TO220, Discrete Semiconductor Products~Transistors - IGBTs - Single
