SSU1N50BTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET N-CH 520V 1.3A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SSU1N50BTU Specifications:
- MfrPart.: SSU1N50BTU
- Mfr: onsemi
- Description: MOSFET N-CH 520V 1.3A IPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Not For New Designs
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 520 V
- Current-ContinuousDrain(Id)@25°C: 1.3A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 5.3Ohm @ 650mA, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 11 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 340 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 2.5W (Ta), 26W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- SSU1N50BTU onsemi (ON), MOSFET N-CH 520V 1.3A IPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
