SSM1N45BTF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-223-4
- Description: MOSFET N-CH 450V 500MA SOT223-4
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SSM1N45BTF Specifications:
- MfrPart.: SSM1N45BTF
- Mfr: onsemi
- Description: MOSFET N-CH 450V 500MA SOT223-4
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 450 V
- Current-ContinuousDrain(Id)@25°C: 500mA (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 4.25Ohm @ 250mA, 10V
- Vgs(th)(Max)@Id: 3.7V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 8.5 nC @ 10 V
- Vgs(Max): ±50V
- InputCapacitance(Ciss)(Max)@Vds: 240 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 900mW (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-223-4
- SSM1N45BTF onsemi (ON), MOSFET N-CH 450V 500MA SOT223-4, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
