SSH70N10A Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-3PN
- Description: MOSFET N-CH 100V 70A TO3PN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SSH70N10A Specifications:
- MfrPart.: SSH70N10A
- Mfr: onsemi
- Description: MOSFET N-CH 100V 70A TO3PN
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 70A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 23mOhm @ 35A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 195 nC @ 10 V
- Vgs(Max): -
- InputCapacitance(Ciss)(Max)@Vds: 4870 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 300W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-3PN
- SSH70N10A onsemi (ON), MOSFET N-CH 100V 70A TO3PN, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
