SSD2009ATF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: MOSFET 2N-CH 50V 3A 8-SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SSD2009ATF Specifications:
- MfrPart.: SSD2009ATF
- Mfr: onsemi
- Description: MOSFET 2N-CH 50V 3A 8-SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tube
- Series: -
- PartStatus: Obsolete
- FETType: 2 N-Channel (Dual)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 50V
- Current-ContinuousDrain(Id)@25°C: 3A
- RdsOn(Max)@IdVgs: 130mOhm @ 3A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 25nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: -
- Power-Max: 2W
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- SSD2009ATF onsemi (ON), MOSFET 2N-CH 50V 3A 8-SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
SSD2009ATF, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
