SS0503EC-TR-H Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: 2-UDFN
- Description: DIODE SCHOTTKY 30V 500MA 2ECSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SS0503EC-TR-H Specifications:
- Manufacturer Product Number: SS0503EC-TR-H
- Mfr: onsemi
- Detailed Description: DIODE SCHOTTKY 30V 500MA 2ECSP
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Bulk
- Series: -
- Part Status: Obsolete
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30 V
- Current - Average Rectified (Io): 500mA
- Voltage - Forward (Vf) (Max) @ If: 560 mV @ 500 mA
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 10 ns
- Current - Reverse Leakage @ Vr: 100 µA @ 15 V
- Capacitance @ Vr, F: 6pF @ 10V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: 2-UDFN
- Operating Temperature - Junction: -55°C ~ 125°C
- SS0503EC-TR-H onsemi (ON), DIODE SCHOTTKY 30V 500MA 2ECSP, Discrete Semiconductor Products~Diodes - Rectifiers - Single
SS0503EC-TR-H, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
