SNXH80T120L2Q0P2G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IC MODULE PIM 1200V 80A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SNXH80T120L2Q0P2G Specifications:
- MfrPart.: SNXH80T120L2Q0P2G
- Mfr: onsemi
- Description: IC MODULE PIM 1200V 80A
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tray
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Three Level Inverter
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 67 A
- Power-Max: 158 W
- Vce(on)(Max)@VgeIc: 2.85V @ 15V, 80A
- Current-CollectorCutoff(Max): 300 µA
- InputCapacitance(Cies)@Vce: 19.4 nF @ 20 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- SNXH80T120L2Q0P2G onsemi (ON), IC MODULE PIM 1200V 80A, Discrete Semiconductor Products~Transistors - IGBTs - Modules
