SNXH100M95H3Q2F2PG Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IC MODULE PIM 100V
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SNXH100M95H3Q2F2PG Specifications:
- MfrPart.: SNXH100M95H3Q2F2PG
- Mfr: onsemi
- Description: IC MODULE PIM 100V
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tray
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Configuration: Full Bridge Inverter
- Voltage-CollectorEmitterBreakdown(Max): 950 V
- Current-Collector(Ic)(Max): 85 A
- Power-Max: 193 W
- Vce(on)(Max)@VgeIc: 2.25V @ 15V, 150A
- Current-CollectorCutoff(Max): 400 µA
- InputCapacitance(Cies)@Vce: 9.546 nF @ 20 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: 175°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- SNXH100M95H3Q2F2PG onsemi (ON), IC MODULE PIM 100V, Discrete Semiconductor Products~Transistors - IGBTs - Modules
