SMMBT2369ALT1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-236-3, SC-59, SOT-23-3
- Description: TRANS NPN 15V 0.2A SOT23
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SMMBT2369ALT1G Specifications:
- MfrPart.: SMMBT2369ALT1G
- Mfr: onsemi
- Description: TRANS NPN 15V 0.2A SOT23
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 200 mA
- Voltage-CollectorEmitterBreakdown(Max): 15 V
- VceSaturation(Max)@IbIc: 500mV @ 10mA, 100mA
- Current-CollectorCutoff(Max): 400nA
- DCCurrentGain(hFE)(Min)@IcVce: 20 @ 100mA, 1V
- Power-Max: 225 mW
- Frequency-Transition: -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-236-3, SC-59, SOT-23-3
- SMMBT2369ALT1G onsemi (ON), TRANS NPN 15V 0.2A SOT23, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
SMMBT2369ALT1G, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
