SMBT3946DW1T1G Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays Package/Case: 6-TSSOP, SC-88, SOT-363
- Description: TRAN NPN/PNP 40V 0.2A SC88/SC70
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SMBT3946DW1T1G Specifications:
- MfrPart.: SMBT3946DW1T1G
- Mfr: onsemi
- Description: TRAN NPN/PNP 40V 0.2A SC88/SC70
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- TransistorType: NPN, PNP
- Current-Collector(Ic)(Max): 200mA
- Voltage-CollectorEmitterBreakdown(Max): 40V
- VceSaturation(Max)@IbIc: 300mV @ 5mA, 50mA / 400mV @ 5mA, 50mA
- Current-CollectorCutoff(Max): -
- DCCurrentGain(hFE)(Min)@IcVce: 100 @ 10mA, 1V
- Power-Max: 150mW
- Frequency-Transition: 300MHz, 250MHz
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 6-TSSOP, SC-88, SOT-363
- SMBT3946DW1T1G onsemi (ON), TRAN NPN/PNP 40V 0.2A SC88/SC70, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Arrays
