SGW13N60UFDTM Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 600V 13A 60W D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGW13N60UFDTM Specifications:
- MfrPart.: SGW13N60UFDTM
- Mfr: onsemi
- Description: IGBT 600V 13A 60W D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 13 A
- Current-CollectorPulsed(Icm): 52 A
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 6.5A
- Power-Max: 60 W
- SwitchingEnergy: 85µJ (on), 95µJ (off)
- InputType: Standard
- GateCharge: 25 nC
- Td(on/off)@25°C: 20ns/70ns
- TestCondition: 300V, 6.5A, 50Ohm, 15V
- ReverseRecoveryTime(trr): 55 ns
- OperatingTemperature: -
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- SGW13N60UFDTM onsemi (ON), IGBT 600V 13A 60W D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
