SGS6N60UFTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 6A 22W TO220F
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGS6N60UFTU Specifications:
- MfrPart.: SGS6N60UFTU
- Mfr: onsemi
- Description: IGBT 600V 6A 22W TO220F
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 6 A
- Current-CollectorPulsed(Icm): 25 A
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 3A
- Power-Max: 22 W
- SwitchingEnergy: 57µJ (on), 25µJ (off)
- InputType: Standard
- GateCharge: 15 nC
- Td(on/off)@25°C: 15ns/60ns
- TestCondition: 300V, 3A, 80Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- SGS6N60UFTU onsemi (ON), IGBT 600V 6A 22W TO220F, Discrete Semiconductor Products~Transistors - IGBTs - Single
