SGR6N60UFTF Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: IGBT 600V 6A 30W DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGR6N60UFTF Specifications:
- MfrPart.: SGR6N60UFTF
- Mfr: onsemi
- Description: IGBT 600V 6A 30W DPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 6 A
- Current-CollectorPulsed(Icm): 25 A
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 3A
- Power-Max: 30 W
- SwitchingEnergy: 57µJ (on), 25µJ (off)
- InputType: Standard
- GateCharge: 15 nC
- Td(on/off)@25°C: 15ns/60ns
- TestCondition: 300V, 3A, 80Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- SGR6N60UFTF onsemi (ON), IGBT 600V 6A 30W DPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
