SGP23N60UFTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 600V 23A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGP23N60UFTU Specifications:
- MfrPart.: SGP23N60UFTU
- Mfr: onsemi
- Description: IGBT 600V 23A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 23 A
- Current-CollectorPulsed(Icm): 92 A
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 12A
- Power-Max: 100 W
- SwitchingEnergy: 115µJ (on), 135µJ (off)
- InputType: Standard
- GateCharge: -
- Td(on/off)@25°C: 17ns/60ns
- TestCondition: 300V, 12A, 23Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- SGP23N60UFTU onsemi (ON), IGBT 600V 23A TO220-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
SGP23N60UFTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
