SGP10N60RUFDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 600V 16A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGP10N60RUFDTU Specifications:
- MfrPart.: SGP10N60RUFDTU
- Mfr: onsemi
- Description: IGBT 600V 16A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 16 A
- Current-CollectorPulsed(Icm): 30 A
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 10A
- Power-Max: 75 W
- SwitchingEnergy: 141µJ (on), 215µJ (off)
- InputType: Standard
- GateCharge: 30 nC
- Td(on/off)@25°C: 15ns/36ns
- TestCondition: 300V, 10A, 20Ohm, 15V
- ReverseRecoveryTime(trr): 60 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- SGP10N60RUFDTU onsemi (ON), IGBT 600V 16A TO220-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
SGP10N60RUFDTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
