SGL60N90DG3YDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
- Description: IGBT 900V 60A 180W TO264
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGL60N90DG3YDTU Specifications:
- MfrPart.: SGL60N90DG3YDTU
- Mfr: onsemi
- Description: IGBT 900V 60A 180W TO264
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench
- Voltage-CollectorEmitterBreakdown(Max): 900 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 60A
- Power-Max: 180 W
- SwitchingEnergy: -
- InputType: Standard
- GateCharge: 260 nC
- Td(on/off)@25°C: -
- TestCondition: -
- ReverseRecoveryTime(trr): 1.5 µs
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-3, TO-264AA
- SGL60N90DG3YDTU onsemi (ON), IGBT 900V 60A 180W TO264, Discrete Semiconductor Products~Transistors - IGBTs - Single
