SGL50N60RUFDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
- Description: IGBT 600V 80A TO264-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGL50N60RUFDTU Specifications:
- MfrPart.: SGL50N60RUFDTU
- Mfr: onsemi
- Description: IGBT 600V 80A TO264-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 150 A
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 50A
- Power-Max: 250 W
- SwitchingEnergy: 1.68mJ (on), 1.03mJ (off)
- InputType: Standard
- GateCharge: 145 nC
- Td(on/off)@25°C: 26ns/66ns
- TestCondition: 300V, 50A, 5.9Ohm, 15V
- ReverseRecoveryTime(trr): 100 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-3, TO-264AA
- SGL50N60RUFDTU onsemi (ON), IGBT 600V 80A TO264-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
