SGL40N150TU onsemi IGBT 1500V 40A 200W TO264
SGL40N150TU Images
SGL40N150TU Images
SGL40N150TU
  • Manufacturer: onsemi (ON)
  • Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
  • Description: IGBT 1500V 40A 200W TO264
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SGL40N150TU Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SGL40N150TU Specifications:
  • MfrPart.: SGL40N150TU
  • Mfr: onsemi
  • Description: IGBT 1500V 40A 200W TO264
  • Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • IGBTType: -
  • Voltage-CollectorEmitterBreakdown(Max): 1500 V
  • Current-Collector(Ic)(Max): 40 A
  • Current-CollectorPulsed(Icm): 120 A
  • Vce(on)(Max)@VgeIc: 4.7V @ 15V, 40A
  • Power-Max: 200 W
  • SwitchingEnergy: -
  • InputType: Standard
  • GateCharge: 140 nC
  • Td(on/off)@25°C: -
  • TestCondition: -
  • ReverseRecoveryTime(trr): -
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-264-3, TO-264AA
  • SGL40N150TU onsemi (ON), IGBT 1500V 40A 200W TO264, Discrete Semiconductor Products~Transistors - IGBTs - Single
