SGL160N60UFDTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-264-3, TO-264AA
- Description: IGBT 600V 160A 250W TO264
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGL160N60UFDTU Specifications:
- MfrPart.: SGL160N60UFDTU
- Mfr: onsemi
- Description: IGBT 600V 160A 250W TO264
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Not For New Designs
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 160 A
- Current-CollectorPulsed(Icm): 300 A
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 80A
- Power-Max: 250 W
- SwitchingEnergy: 2.5mJ (on), 1.76mJ (off)
- InputType: Standard
- GateCharge: 345 nC
- Td(on/off)@25°C: 40ns/90ns
- TestCondition: 300V, 80A, 3.9Ohm, 15V
- ReverseRecoveryTime(trr): 95 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-264-3, TO-264AA
- SGL160N60UFDTU onsemi (ON), IGBT 600V 160A 250W TO264, Discrete Semiconductor Products~Transistors - IGBTs - Single
SGL160N60UFDTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
