SGH80N60UFTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 600V 80A 195W TO3P
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGH80N60UFTU Specifications:
- MfrPart.: SGH80N60UFTU
- Mfr: onsemi
- Description: IGBT 600V 80A 195W TO3P
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 220 A
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 40A
- Power-Max: 195 W
- SwitchingEnergy: 570µJ (on), 590µJ (off)
- InputType: Standard
- GateCharge: 175 nC
- Td(on/off)@25°C: 23ns/90ns
- TestCondition: 300V, 40A, 5Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- SGH80N60UFTU onsemi (ON), IGBT 600V 80A 195W TO3P, Discrete Semiconductor Products~Transistors - IGBTs - Single
SGH80N60UFTU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
