SGH40N60UFDM1TU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 600V 40A 160W TO3P
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGH40N60UFDM1TU Specifications:
- MfrPart.: SGH40N60UFDM1TU
- Mfr: onsemi
- Description: IGBT 600V 40A 160W TO3P
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 20A
- Power-Max: 160 W
- SwitchingEnergy: 160µJ (on), 200µJ (off)
- InputType: Standard
- GateCharge: 97 nC
- Td(on/off)@25°C: 15ns/65ns
- TestCondition: 300V, 20A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 60 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- SGH40N60UFDM1TU onsemi (ON), IGBT 600V 40A 160W TO3P, Discrete Semiconductor Products~Transistors - IGBTs - Single
SGH40N60UFDM1TU, onsemi authentic parts in stock from onsemi (ON) authorized distributors, order today, can ship immediately.
