SGH30N60RUFTU Images
- Manufacturer: onsemi (ON)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 600V 48A 235W TO3P
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SGH30N60RUFTU Specifications:
- MfrPart.: SGH30N60RUFTU
- Mfr: onsemi
- Description: IGBT 600V 48A 235W TO3P
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 48 A
- Current-CollectorPulsed(Icm): 90 A
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 30A
- Power-Max: 235 W
- SwitchingEnergy: 919µJ (on), 814µJ (off)
- InputType: Standard
- GateCharge: 85 nC
- Td(on/off)@25°C: 30ns/54ns
- TestCondition: 300V, 30A, 7Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- SGH30N60RUFTU onsemi (ON), IGBT 600V 48A 235W TO3P, Discrete Semiconductor Products~Transistors - IGBTs - Single
